ATM10 – Atmospheric Pressure Sensor

The ATM10 sensor is designed for continuous measurement of atmospheric air pressure in meteorological and environmental applications. The sensor uses a precise, temperature-compensated sensor that ensures stable and long-term accurate measurements.

The measured values are transmitted via RS485 digital communication to a connected telemetry unit or data logger.

Measurement of atmospheric air pressure
Temperature-compensated sensor
RS485 digital communication
High accuracy and stability
Compact design

Non-binding inquiry

Description

The sensor is designed for long-term outdoor operation and can be installed in a radiation shield or directly in a telemetry station. Its compact design allows for easy integration into measurement systems.

Thanks to its high stability and accuracy, it is suitable for professional meteorological measurements.

Applications

Weather stations
Environmental monitoring
Agricultural applications
Hydrological projects
Industrial applications

Technical specifications

Technical Specifications	ATM10
Measured Quantity	atmospheric air pressure
Pressure Range	300 – 1100 mbar
Resolution	up to 0.025 mbar
Communication	RS485 (FINET / Modbus RTU)
Power Supply	6 – 16 V DC
Connector	M12
